MDE-4699L Applause™ Media System Installation, Service, and Parts Manual · June 2017 Page 5-11
Troubleshooting Service
28 Turn off the server by holding the POWER button on the front of the server for a period of
four seconds.
Following table provides an overview of the
BIOS settings for Gilbarco Site Server (Silver
Server):
Configuring BIOS on Gilbarco Site Server [Black Server (PA03580002)]
To configure BIOS on Gilbarco Site Server, proceed as follows:
The BIOS on the Gilbarco Site Server is factory-set. Use this configuration
procedure only if the BIOS is lost or corrupted.
CAUTION
Note: Power supply must be maintained to the Gilbarco Site Server in the event of a power
failure. Power connection to a UPS is strongly recommended. Refer to the table for an
overview of the BIOS settings.
To configure the BIOS in the Gilbarco
Site Server, proceed as follows:
1 Connect the monitor and keyboard to the server.
2 Turn on the server.
Item Setting
Standard CMOS Features
Time and Date Use Page Up and Page Down keys to change values
IDE Channel 0 Master Any value other than “None”
IDE Channel 0 Slave
~ OR ~
IDE Channel 1 Master
Any value other than “None”
Standard CMOS Features > IDE Channel 0 Master
Access Mode LBA
Standard CMOS Features > IDE Channel 0 Master > IDE HDD Auto-Detection
Drive A 1.44 M, 3.5 inches (if floppy drive is present);
otherwise “None”
Advanced BIOS Features
First Boot Device CDROM
Second Boot Device Hard Disk
Advanced Chipset Features > AGP & P2P Bridge Control
VGA Share Memory Size 16 M (or smallest value that is not “Disabled”)
Power Management Setup
Soft-off by PWRBTN Delay 4 sec
Power Fail Resume On
To Next Page
