MDE-4699L Applause™ Media System Installation, Service, and Parts Manual · June 2017 Page B-1
Site Is DSL/Cable LAN Network Setup Information Sheet
Appendix B – Setup Information Sheet
Site Is DSL/Cable LAN Network
IP Addresses
Item/Name Information Where Used Value
Static Public IP This value must be obtained from “Site Network Contact”. Site Router IP
Public Primary DNS IP This value must be obtained from “Site Network Contact”. Applause Media System DNS
Server
Address 1
Public Secondary DNS IP This value must be obtained from “Site Network Contact”. Applause Media System DNS
Server
Address 2
Local Default Gateway IP This value must be obtained from “Site Network Contact”. Applause Media System Default
Gateway Address
Local Subnet Mask This value must be obtained from “Site Network Contact”.
A
common value would be “255.255.255.0”.
Applause Media System Netmask
CRIND programming
Local Applause Media System IP This value must be obtained from “Site Network Contact”
(if the site
is not on the default IP scheme).
Applause Media System IP Address
CRIND programming
Local LRE 1 IP This value must be obtained from “Site Network Contact”. LRE #1 programming
Local LRE 2 IP (required only
when site has more then
16
fueling positions)
This value must be obtained from “Site Network Contact”. LRE #2 programming
Local LRE 3 IP (required only
when site has more then
24
fueling positions)
This value must be obtained from “Site Network Contact”. LRE #3 programming
Local Dispenser IPs (usually
additiona
l dispensers numbered
sequentially)
This value must be obtained from “Site Network Contact”. CRIND programming
Port Forwarding
Note: Optionally, these ports may be masked.
Item/Name Information Where Used Value
Applause Media System IP Ports 443 Can be masked for incoming access 22 Site Router 443, 22
LRE IP Ports 443 Can be masked for incoming access 22 Site Router 23
