Service Troubleshooting
Page 5-18 MDE-4699L Applause™ Media System Installation, Service, and Parts Manual · June 2017
Gbe Wake Power Via GPIO Disabled
Resume by PCI Device (PME#) Enabled
Resume by RTC Alarm Disabled
PnP/PCI Configurations
Clear ESCD
No -
Initiate Graphic Adapter
PEG/PCI -
PCI Latency Timer
64 -
PCI Slot 1
Auto -
PCI Slot 2 IRQ
Auto -
IRQ Resource Setup
Slot2 Auto
IRQ3 Available
IRQ4 Available
IRQ5 Available
IRQ7 Available
IRQ9 Available
IRQ10 Available
IRQ11 Available
IRQ14 Available
IRQ15 Available
DMA Resource Setup
DMA Channel 0 Available
DMA Channel 1 Available
DMA Channel 3 Available
DMA Channel 5 Available
DMA Channel 6 Available
DMA Channel 7 Available
H/W Monitor
CPU FAN Target Temp Value
60 -
Chassis Intrusion
Disabled -
SMART FAN1 Target
104 °F (40 °C) -
SMART FAN1 Tolerance
5% -
All Others
(As reported) -
Note: Parameters may vary from system to system depending on the server you are using.
Item Setting Status
