Page C-2 MDE-4699L Applause™ Media System Installation, Service, and Parts Manual · June 2017
Configuring Site Server IP Addresses for Applause Media System (when IP Addresses Are Changed)
Figure C-2: Connecting Through LRE, BRCM, or Switch
LRE, BRCM, or
Switch (LRE Shown)
Standard CAT-5 Cable
Laptop
Note: This laptop connection could also be plugged directly to a router.
2 Access the programming web page by typing the IP address of the site server in your browser.
The Gilbarco default IP address is 10.5.48.66 but your site server IP address will be different,
if using a different IP address scheme at the site.
If the encryption level of the site server is set t
o “TLS Mode”, begin the URL for connecting to
the site server with “https:”. If the encryption level is set to “Fallback Mode” you may use
either “http:” or “https:” in the URL. If the encryption level is set to “Clear Mode” you must
use “http:” in the URL. For information on setting the encryption level, refer to
“Appendix G - Security Settings for Site Server” on page G-1.
Notes: 1) If using “https:” to connect to the site server
, your browser will display a warning
stating that it cannot verify the security certificate (or similar warning). This is
normal behavior, because the certificate is self signed. When the message is
displayed, select proceed to site anyway (or the appropriate option in your
specific browser).
2) For sites using non-default IP addresses, it may be
required to contact the site’s IT
personnel or the local ASC to obtain important IP address information.
