Introduction
1
1-6 223 Sample Changer User’s Guide
Unpacking
Safety Shield
A safety shield encloses the sides and front of the sample changer working area.
2-conductor Wire
2-conductor wire is required when making contact connections.
Diverting Valve
A diverting valve can be mounted on the sample changer.
Transfer Tubing
Based on your requirements, you also received transfer tubing, ordered separately. Refer to Appendix A, Replacement Parts and
Accessories for part numbers.
Probes
A probe is required, but not included, as there are many options to choose from. Refer to Appendix A, Replacement Parts and
Accessories for part numbers.
Racks
Based on your requirements, you also received racks, ordered separately. Refer to Appendix B, Racks for part numbers.
Tray/Tray Spacers
The tray positions the racks and any accessories that fit onto the bed of the sample changer. It also contains liquid spills, such as
those caused by overflowing vessels.
If using tubes that are less than 100 mm in height, the tray will be installed in the upper position and tray spacers will be required.
Part Number Description
1907175 223 Safety Shield kit
Part Number Description
709910206 2-conductor interconnect wire, 6 feet.
Part Number Description
190711 Diverting valve assembly for
223 Sample Changer. Includes mounting
bracket, tubing, and two tubing/cable clips
Part Number Description
19041001 Generic black pan with drain assy
Part Number Description
190710 Tray spacers for installing polypropylene tray in
upper position, package of 2
