103
MDE-LEDInetworkITS-server-4078V1.3
APPENDIX A – CONNECTIONS
3. 18-72VDC
Below is the wiring drawing of the 18-72VDC connector:
4. ALARM
The AFNOR/IRIG-B synchronization input is localized on the backside of the device.
Synchronization is done through a 2 points plug , as shown below:
18-72 VDC
+ -
12 34
Pin 3 & 4 : Power alarm (without polarity)
Pin 1 & 2 : Synchronization alarm (without polarity)
ENGLISH
