APPENDIX E – DATA

MOTHERBOARD :
Input 2 – Time code 1 2 3
Input option card
present
AFNOR DCLS ON ON OFF YES
AFNOR SINE WAVE ON ON ON YES
IEEE1344 DCLS X OFF OFF YES
IEEE1344 SINE WAVE X OFF ON YES
IRIG-B DCLS OFF ON OFF YES
IRIG-B SINE WAVE OFF ON ON YES
NTP X X OFF NO
None X X ON NO
AFNOR / IRIG-B input option card :
Switchs DCLS – TTL
DCLS – RS422
(differential TTL)
Sine wave
1 ON (Right) OFF (Left) OFF (Left)
2 ON (Right) ON (Right) OFF (Left)
3 ON (Right) ON (Right) OFF (Left)
4 ON (Right) ON (Right) OFF (Left)
5 ON (Right) OFF (Left) OFF (Left)
6 – load
ON / OFF
OFF (Left) Left/Right OFF (Left)
7 – inversion
ON / OFF
Left/Right Left/Right OFF (Left)
SW 1
SW 2
SW 3
SW 4
SW 5
SW 6
SW 7
OFF ON
