Parts & Tools Needed:
Instructions
Take the following steps to install the wheel covers onto the machine:
Installing the Wheel Covers
T-handle Allen
Wrench 4 mm
4 mm
SBHCS Screw
M6 x 16 mm (x4)
Plastic Base - Left
Plastic Base - Right
2. Slide the left plastic base onto the left side of the machine. Screw two M6 x 16 mm SBHCS
screws into the plastic base using the 4 mm Allen wrench. Tighten until snug.
1. Slide the right plastic base onto the right side of the machine, over the side ridge. Screw in
place with two M6 x 16 mm SBHCS screws and the 4 mm Allen wrench. Tighten until snug.
2
Out-of-the-Box Assembly
Plastic Base - Left
SBHCS Screw
M6 x 16 mm
(x2)
1
SBHCS Screw
M6 x 16 mm
(x2)
Plastic Base - Right
Side Ridge
