Machine Layout
1. Hand Wheel
Raises and lowers the needle.
2. Bobbin Thread Tensioner (page 27)
Tensions thread for winding a bobbin.
3. Bobbin Thread Cutter (page 27)
Cuts wound bobbin thread.
4. Bobbin Stand (page 27)
Positions bobbin for winding.
5. Bobbin Cam (page 27)
Starts and stops bobbin winding.
6. Thread Stand (page 31)
Holds a cone of thread.
7. Thread Mast (page 31)
Guides the thread for quilting.
8. Bobbin Thread Guide (page 27)
Guides thread for winding a bobbin.
9. Thread Guide Rod (page 31)
Positions thread when quilting.
• Small Thread Tensioner (page 31)
Tensions thread when quilting.
• Thread Guide (page 31)
Positions thread when quilting.
• Take-Up Lever (page 31)
Tensions thread when quilting.
1
3
4
5
6
7
8
11
12
2
Quilting Machine (Side View)
10
9
7
11
13
14
15
10
2
3
6
9
4
19
20
5
8
21
1
12
17
22
18
16
6
