62
Parts & Tools Needed:
Reinstalling the Needle Plate
Flat-head Screwdriver
Removal Instructions
To remove the needle plate from the quilting machine, take the following steps:
Maintaining the Machine
2. Use the at-head screwdriver to remove the
two needle plate screws (shown in gray).
2
1. Power o the machine and raise the needle to the highest position using the hand wheel.
1
3. Slide the needle plate (shown in gray) from
the machine.
3
Hand Wheel
To Next Page
