51
Oiling and Cleaning
Maintaining the Machine
Instructions
Tip: The Hours Run counter on the System Information page can be used to track hours of quilting
time (see page 47).
Take the following steps to clean and oil the machine:
Oil and Clean:
Machine
• At the start of a new project
• After 20 hours of use
• After sitting without use for more than 30 days
Bobbin Case
• Every other bobbin change
Parts & Tools Needed:
Lint Brush
Oil Bottle
• Compressed Air Can (optional; not included)
1. Power o the machine.
2. Set the large thread tensioner setting to “1” to expose the tensioner discs. Use the lint brush
or a can of compressed air to clear away lint and thread remnants.
Note: Lint build-up between the tensioner discs can prevent proper thread tensioning.
Large Thread
Tensioner
2
1
