Power Port with Retainer (page 25)
Connects and holds power cable to the
machine.
Power On/O Switch (page 25)
Turns machine on and o.
Quilt Motion Tablet Port
For optional automation accessory.
USB Connector Port
For updating only.
Quilt Motion Port
For optional automation accessory.
Encoder Ports (page 21)
Connects encoders to machine.
Back Handle Port Cover
For optional back handle accessory.
Display Cable Port (page 19)
Connects display cable to machine.
Display Clip Port (page 19)
Connects display clip to machine.
1
3
4
5
6
7
8
Ports and Plug-Ins
2
9
Quilting Machine (Rear View)
Quilting Machine (Front View)
3
4
2
7
6
1
5
8
9
