58
Hopping Foot
Screw
3. Use the 3 mm Allen wrench to remove the
screw holding the hopping foot.
3
Adjusting the Hopping Foot (Continued)
Maintaining the Machine
2. Rotate the hand wheel to lift the needle
from the hopping foot.
2
Hand Wheel
Hopping Foot
4. Slide the hopping foot from the press bar.
4
5. With the 3 mm Allen wrench, loosen the
collar screw that holds the hopping foot
collar to the press bar.
Rotation Instructions
The hopping foot can be rotated to improve line of sight. To rotate the hopping foot, please take the
following steps.
1. Power o the machine.
1
5
Hopping Foot
Collar
Collar Screw
6. Drop the hopping foot collar below the press
bar and turn it to the desired position.
6
The hopping foot can be set to two positions:
Press Bar
To Next Page
