63
Installation Instructions
To install the needle plate onto the quilting machine, take the following steps:
4. Slowly lower the needle with the hand wheel.
The needle should slide into the center hole
without contacting the needle plate.
4
Reinstalling the Needle Plate (Continued)
Maintaining the Machine
1. Power o the machine. Raise the needle to
the highest position using the hand wheel.
1
5. Place the two needle plate screws (shown
in gray) into the plate. Make sure the needle
plate is centered around the needle, and
then tighten the screws with the at-head
screwdriver.
5
Needle Plate
2. Slide the needle plate onto the machine.
2
3. Align the screw holes on the needle plate
with those on the machine.
3
Hand Wheel
To Next Page
