29
Loading the Bobbin Case
Take the following steps to insert the wound bobbin into the bobbin case and place it in the machine:
Note: If the bobbin is installed correctly in
the case, the bobbin will turn clockwise when
the thread is pulled.
Preparing to Quilt
Release
Lever
3. Pull on the bobbin case release lever to
remove the bobbin case from the hook
assembly.
3
2. Press the Menu button on the handlebar
controls to go to the Main Menu and
deactivate stitching.
2
4. Place the wound bobbin into the bobbin
case. Note the direction that the thread is
coming o the bobbin in relation to the case.
Bobbin
Case
4
5. Slip a few inches of thread through the slot
and out of the hole.
Slot
Hole
5
1. Check that the needle is up. If needed,
rotate the hand wheel to raise the needle.
1
Hand Wheel
Menu
To Next Page
