28
3. Pull the thread through the hole in the
tensioner thread guide and then around
the back of the bobbin thread tensioner,
between the two discs.
Bobbin
Thread
Tensioner
Tensioner
Thread Guide
3
1. Run the thread through the thread mast
guide loop directly above the thread cone.
1
Guide Loop
Thread Mast
2. Feed the thread through the front of the
rst hole (closest to the thread cone) on
the bobbin thread guide. Then wrap it
back over and pass through the front of the
second hole.
2
Bobbin Thread
Guide
Winding a Bobbin (Continued)
Preparing to Quilt
4. Tightly wrap the thread clockwise around
the bobbin a few times to hold the thread
in place. Push the bobbin cam toward the
bobbin to start winding.
Bobbin Cam
4
5. Winding stops automatically when the
bobbin is full. Cut the thread with the
thread cutter near the bobbin cam.
Note: Bobbin ll levels can be adjusted (see
page 56).
Thread
Cutter
5
The bobbin thread should appear neat and
smooth.
