Removal Instructions
To remove the hopping foot for maintenance or to adjust the hopping foot angle, take the following
steps:
1. Power o the machine.
2. Rotate the hand wheel to lift the needle from the inside of the hopping foot.
1
2
Hopping Foot
Screw
3. Use the 3 mm Allen wrench to remove the screw holding the hopping foot.
3
Adjusting the Hopping Foot (Continued)
Maintaining the Machine
Hopping Foot
The hopping foot now slides free from the press bar.
Hand Wheel
