Troubleshooting
333587B 59
EKA Pump Record
Only
Automatic
Crossover to P_
The system has
success
crossover to the
other the other
pump
The alarm in the
system requested a
crossover to the
other pump
No action necessary.
EKM Pump Record
Only
Manual
Crossover to P_
The system has
received a
crossover
request
The system has
received a
crossover request
from the ADM or
CGM
No action necessary.
EL0X ADM Record
Only
Power On The ADM was
powered on
The ADM was
powered on
No action necessary.
EM0X ADM Record
Only
Power Off The ADM was
powered off
The ADM was
powered off
No action necessary.
EVUX ADM Advisory USB Disabled USB
downloads/uplo
ads are
disabled
USB
download/upload
was attempted, but
USB activity is
disabled within the
setup screen
Advisory will clear when drive is removed.
Enable USB downloads/uploads in setup
screen if desired and reinsert USB drive.
F1D_
F2D_
Pump Alarm or
Deviation
(user
selectable)
Low Flow Rate
P_
Measured flow
rate less than
desired flow
rate minus
tolerance
Fluid supply too low
to achieve desired
flow rate
Increase fluid pressure to reach desired rate.
Clog in fluid supply
system
Check hose and other components in fluid
supply system for clogs.
No air pressure to
solenoid valves
Turn on air to solenoid valves.
No material supply Replace drum and prime pump if desired.
Incorrect flow
tolerance
Enter correct flow tolerance percentage in
setup screen.
F3D_
F4D_
Pump Alarm or
Deviation
(user
selectable)
High Flow Rate
P_
Measured flow
rate greater
than desired
flow rate plus
tolerance
Incorrect flow
tolerance
Enter correct flow tolerance percentage in
setup screen.
L1C_ Pump Alarm Drum Empty P_ Drum is empty Drum is empty and
needs to be
replaced
Replace drum and prime pump if desired.
Drum level sensor
is disconnected
Verify level sensor is connected. Replace
sensor if connection is good.
L2C_ Pump Deviation Drum Empty P_ Drum level is
low
Fluid level in drum
is low. Consider
replacing soon
Clear deviation and return to normal pump
operation.
Drum level sensor
is disconnected
Verify level sensor is connected. Replace
sensor if connection is good.
MMUX ADM Advisory USB Log 90%
Full
One or more
USB log is 90%
full.
Data in the jobs or
events log has not
been downloaded
recently and logs
are nearly full
Download the data or disable USB errors.
Error Location Type Error Name
Error
Description
Cause Solution
