Integration
72 333587B
Automation Inputs
E-Flo iQ Advance Map 18A915
Automation INPUTS (signal from E-Flo iQ to PLC )
Instance ID Description Data Type Bit Byte Heat
1
Pump Heartbeat To PLC Boolean 0
0

2
Automation Control Ready Boolean 1 
3
System Active Boolean 2 
4
PLC Lockout/Control Active Boolean 3 
5
No Alarms Active Boolean 4 
6
No Deviations Active Boolean 5 
7
No Advisory Active Boolean 6 
8
System Ready to dispense Boolean 7 
9
Pre-charge / De-charge Active Boolean 0
1

10
Dispense In Process Boolean 1 
11
Drum Is Low Boolean 2 
12
Drum Is Empty Boolean 3 
13
Pump Not Primed Boolean 4 
14
Pump in Job Cycle Boolean 5 
15
Prime Active Boolean 6 
16
Valve Depressurization Active Boolean 7 
17
Platen Depressurization Active Boolean 0
2

18
Auto Depressurization Active Boolean 1 
19
Auto Depressurization Happened Boolean 2 
20
Pump is trying to move Boolean 3 
21
Pump is actually moving Boolean 4 
22
Dispense Valve Opened Boolean 5 
Platen Valve Opened Boolean 6 
24
Tandem Active Pump (Tandem System only)
(0 = Pump 1, 1 = Pump 2)
Boolean 7

25

26
E-Flo iQ Mode Active Boolean 0
3

27
Change over Occurred Boolean 1 
28
Reserved Bit 1 Boolean 2 
29
Reserved Bit 2 Boolean 3 
30
Reserved Bit 3 Boolean 4 
31
Reserved Bit 4 Boolean 5 
Reserved Bit 5 Boolean 6 
32
Reserved Bit 6 Boolean 7 
33
Actual Pump Flowrate (xxxx cc/min) uint16 0-15 4-5 
34
Outlet Pressure (xxx.x bar) uint16 0-15 6-7 
35
Valve Pressure (xxx.x bar) uint16 0-15 8-9 
36
Active Style Loaded uint16 0-15 10-11 
37
Active Style Precharge (xxx.x bar) uint16 0-15 12-13 
38
Active Style Flowrate (xxxx cc/min) uint16 0-15 14-15 
