Graco E-Flo iQ - Page 73

Integration
333587B 73
39 Active Style Shot Size (xxx.xx cc) uint16 0-15 16-17 
40
Actual Amount Dispensed
(xxx.xx cc)
uint32 0-31 18-21

41
Actual Shot Size
(xxx.xx cc)
uint32 0-31 22-25

42
Actual Style Fieldbus Pre-charge Request
(xxx.x bars)
uint16 0-15 26-27

43
Actual Style Fieldbus Flowrate Request
(xxxx cc/min)
uint16 0-15 28-29

44
Actual Style Fieldbus Shot Size Request
(xxx.xx cc)
uint16 0-15 30-31

45
Pump Position (x.xxxx inches) uint16 0-15 32-33 
46
Data Exchange Active Command uint16 0-15 34-35 
47
Data Exchange Active Command Value uint32 0-31 36-39 
48
Heartbeat To PLC Boolean 0
40

49
Automation Ready/Remote Control Boolean 1 
50
System Active Boolean 2 
51
PLC Lockout/Control Active Boolean 3 
52
No Alarms Active Boolean 4 
53
No Deviations Active Boolean 5 
54
No Advisory Active Boolean 6 
55
System Ready to dispense Boolean 7 
56
Pre-charge / De-charge Active Boolean 0
41

57
Dispense In Process Boolean 1 
58
Drum Is Low Boolean 2 
59
Drum Is Empty Boolean 3 
60
Pump Not Primed Boolean 4 
61
Pump in Job Cycle Boolean 5 
62
Prime Active Boolean 6 
63
Valve Depressurization Active Boolean 7 
64
Platen Depressurization Active Boolean 0
42

65
Auto Depressurization Active Boolean 1 
66
Auto Depressurization Happened Boolean 2 
67
Pump is trying to move Boolean 3 
68
Pump is actually moving Boolean 4 
69
Dispense Valve Opened Boolean 5 
Platen Valve Opened Boolean 6 
70
Tandem Active Pump (Tandem System only)
(0 = Pump 1, 1 = Pump 2)
Boolean 7

71

