Integration
333587B 75
 Used for ambient map 18A909.
† Additional for heated map 18A915.
117
Heat Module Data Exchange Active Command uint16 0-15 60-61 †
118
Heat Module Data Exchanged Active Command Value uint32 0-31 62-65 †
122
Heat Heartbeat To PLC Boolean 0
66
†
123
System Heat Enabled Boolean 1 †
124
Heat PLC Lockout/Control Active Boolean 2 †
125
Heat is On Boolean 3 †
126
Heat is Warming Up Boolean 4 †
127
Heat is At Temperature Boolean 5 †
128
Heat is in Temperature Soak Mode Boolean 6 †
129
Heat is in Setback Mode Boolean 7 †
130
Heat is Off Boolean 0
67
†
131
No Heat Module Alarms Active Boolean 1 †
132
No Heat Module Deviations Active Boolean 2 †
133
No Heat Module Advisories Active Boolean 3 †
134
No Heat Zone(s) Alarms Active Boolean 4 †
135
No Heat Zone(s) Deviations Active Boolean 5 †
136
No Heat Zone(s) Advisories Active Boolean 6 †
137
Heat Idle Timeout Happened Boolean 7 †
138
Reserved Bit 1 Boolean 0
68
†
139
Reserved Bit 2 Boolean 1 †
140
Reserved Bit 3 Boolean 2 †
141
Reserved Bit 4 Boolean 3 †
142
Reserved Bit 5 Boolean 4 †
143
Reserved Bit 6 Boolean 5 †
144
Reserved Bit 7 Boolean 6 †
145
Reserved Bit 8 Boolean 7 †
146
Reserved Bit 9 Boolean 0
69
†
147
Reserved Bit 10 Boolean 1 †
148
Reserved Bit 11 Boolean 2 †
149
Reserved Bit 12 Boolean 3 †
150
Reserved Bit 13 Boolean 4 †
151
Reserved Bit 14 Boolean 5 †
152
Reserved Bit 15 Boolean 6 †
153
Reserved Bit 16 Boolean 7 †
154
Module Heat Soak Time Reminding (xx seconds) uint16 0-15 70-71 †
155
Heat Module Data Exchange Active Command uint16 0-15 72-73 †
156
Heat Module Data Exchanged Active Command Value uint32 0-31 74-77 †
Key
Active Pump
Inactive Pump on Tandem
Heat Module 1
Heat Module 2
