Automation Outputs
E-Flo iQ Advance Map 18A915
Automation OUTPUTS (signal from PLC to E-Flo iQ )
Instance ID Description Data Type Bit Byte Heat
1
SYS - Data Exchange Command uint16 0-15 0-1 
2
System Enable/Remote Start Request Boolean 0
2

3
System Disable Request Boolean 1 
4
PLC Lockout/Control Boolean 2 
5
Style Enable Boolean 3 
6
Go Signal Boolean 4 
7
Dispense Complete Boolean 5 
8
Tandem Crossover Request Boolean 6 
9
Prime Inactive Pump Request Boolean 7 
10
Valve Depressurization Request Boolean 0
3

11
Platen Depressurization Request Boolean 1 
12
Auto Depressurization Cancel Request Boolean 2 
13
Acknowledge / Clear Errors (both pumps) Boolean 3 
14
Reserved Bit 1 Boolean 4 
15
Reserved Bit 2 Boolean 5 
16
Reserved Bit 3 Boolean 6 
17
Reserved Bit 4 Boolean 7 
18
Desired Active Style Number uint16 0-15 4-5 
19
Style Fieldbus Pre-charge Request
(xxx.x bars)
uint16 0-15 6-7 
20
Style Fieldbus Flow-rate Request
(xxxx cc/min)
uint16 0-15 8-9 
21
Style Fieldbus Shot Size Request
(xxx.xx cc)
uint16 0-15 10-11 
22
Prime Pressure Target (xxx.x bar) uint16 0-15 12-13 
23
Prime Flow Target (xxxx cc/min) uint16 0-15 14-15 
42
System Heat Enabled Request Boolean 0
16
†
43
System Heat Disable Request Boolean 1 †
44
Heat PLC Lockout/Control Boolean 2 †
45
Heat On Request Boolean 3 †
46
Heat Off Request Boolean 4 †
47
Heat Setback Request Boolean 5 †
48
Acknowledge / Clear Heat Errors Boolean 6 †
49
Reserved Bit 1 Boolean 7 †
