Integration
333587B 77
 Used for ambient map 18A909.
† Used for heated map 18A915.
50
Reserved Bit 2 Boolean 0
17
†
51
Reserved Bit 3 Boolean 1 †
52
Reserved Bit 4 Boolean 2 †
53
Reserved Bit 5 Boolean 3 †
54
Reserved Bit 6 Boolean 4 †
55
Reserved Bit 7 Boolean 5 †
56
Reserved Bit 8 Boolean 6 †
57
Reserved Bit 9 Boolean 7 †
Heat Module Data Exchange Command uint16 0-15 18-19 †
Heat Module Data Exchanged Command
Desired Value
uint32 0-31 20-23
†
63
System Heat Enabled Request Boolean 0
24
†
64
System Heat Disable Request Boolean 1 †
65
Heat PLC Lockout/Control Boolean 2 †
66
Heat On Request Boolean 3 †
67
Heat Off Request Boolean 4 †
68
Heat Setback Request Boolean 5 †
69
Acknowledge / Clear Heat Errors Boolean 6 †
70
Reserved Bit 1 Boolean 7 †
71
Reserved Bit 2 Boolean 0
25
†
72
Reserved Bit 3 Boolean 1 †
73
Reserved Bit 4 Boolean 2 †
74
Reserved Bit 5 Boolean 3 †
75
Reserved Bit 6 Boolean 4 †
76
Reserved Bit 7 Boolean 5 †
77
Reserved Bit 8 Boolean 6 †
78
Reserved Bit 9 Boolean 7 †
79
Heat Module Data Exchange Command uint16 0-15 26-27 †
80
Heat Module Data Exchanged Command
Desired Value
uint32 0-31 28-31
†
Key
Active Pump
Inactive Pump on Tandem
Heat Module 1
Heat Module 2
