Pump Data Exchange
Heat Data Exchange
E-Flo iQ Advance Map 18A915
Data Exchange (Pump)
Command Value
(base 10 decimal)
Name Units/Format
0 Pump Active Alarms Bitfield
1 Pump Active Deviations Bitfield
2 Pump Active Advisories Bitfield
3 Driver Resettable Cycles Cycles
4 Pump Resettable Cycles Cycles
5 Platen Resettable Cycles Cycles
6 Dispense Valve Resettable Cycles Cycles
7 Platen Vavle Resettable Cycles Cycles
8 Driver Lifetime Cycles Cycles
9 Pump Lifetime Cycles Cycles
10 Platen Lifetime Cycles Cycles
11 Dispense Valve Lifetime Cycles Cycles
12 Platen Vavle Lifetime Cycles Cycles
13 Pump Direction
Bit Number:
0: FIRST DOWN
1: UP
2 DOWN
3: TOP CHANGEOVER
4: BOT CHANGEOVER
14 Average Motor Current x.xxx Amps
15 Motor Temperature xx deg C
16 IGBT Board Temperature xx deg C
17 Bus Voltage xxx.xx Volts
E-Flo iQ Advance Map 18A915
Data Exchange (Heat Module Data Exchanged)
Note: the "x" in the command value corrsponds to the zone you are wanting to read
Command Value
(hexdemical)
Name Units/Format
0 AMZ Active Module Alarms Bitfield
1 AMZ Active Module Deviations Bitfield
2 AMZ Active Module Advisories Bitfield
3 I/O Daughter Board Active Module Alarms Bitfield
4 I/O Daughter Board Active Module Deviations Bitfield
5 I/O Daughter Board Active Module Advisories Bitfield
6 High Temperature Alarm Offset xx deg C
7 High Temperature Deviation Offset xx deg C
8 Low Temperature Alarm Offset xx deg C
9 Low Temperature Deviation Offset xx deg C
