Pump Error Codes
Pump Active Alarms
Bit
Number
Alarm
Code
Alarm Name
0 V1M_ Low Voltage P_
1 V4M_ High Voltage P_
2 T4M_ High Motor Temperature P_
3 T4J_ High Controls Temperature P_
4 WBD_ Encoder Hardware P_
5 WMN_ Software Mismatch P_
6 CCN_ Control Board P_
7 A4N_ High Motor Current P_
8 WMC_ Control Board P_
9 A4J_ High Motor Current P_
10 DD4_ Pump Diving P_
11 P4C_ High Pressure P_
12 P1C_ Low Pressure P_
13 F4D_ High Flow Rate P_
14 F1D_ Low Flow Rate P_
15 P6D_ Outlet Pressure Sensor P_
16 DKC_ Crossover Error P_
17 L1C_ Drum Empty P_
18 DB1_ Pump Not Primed P_
19 CCG_ Fieldbus Comm. Error P_
20 CAC_ Display Comm. Error P_
21 P6V_ Valve Pressure Sensor P_
22 WSN_ Invalided Style P_
23 WNC_ iQ Software Not Selected P_
24 WMH_ Control Board Off P_
25 - Reserved
26 - Reserved
27 - Reserved
28 - Reserved
29 - Reserved
30 - Reserved
31 - Reserved
Pump Active Deviation
Bit
Number
Deviation
Code
Deviation Name
0 T2J_ Motor Temperatures Sensor P_
1 T3J_ Temperature Cutback P_
2 WSC_ Encoder Calibration P_
3 DD3_ Pump Diving P_
4 P3C_ High Pressure P_
5 P2C_ Low Pressure P_
6 F3D_ High Flow Rate P_
7 F2D_ Low Flow Rate P_
8 P6D_ Outlet Pressure Sensor P_
9 L2C_ Drum Low P_
10 DB2_ Pump Not Primed P_
11 - Reserved
12 - Reserved
13 - Reserved
14 - Reserved
15 - Reserved
16 - Reserved
17 - Reserved
18 - Reserved
19 - Reserved
20 - Reserved
21 - Reserved
22 - Reserved
23 - Reserved
24 - Reserved
25 - Reserved
26 - Reserved
27 - Reserved
28 - Reserved
29 - Reserved
30 - Reserved
31 - Reserved
