Pressure Relief Procedure
20 310648P
6. Engage piston safety lock (L), page 10.
TI3850a
L
WARNING
If fluid in the hose and proportioner is still under pres-
sure, follow the Pressure Relief Procedure in the pro-
portioner manual.
To relieve pressure in the hose after the gun is
removed, place the fluid manifold over containers, fac-
ing away from you. Very carefully open the fluid
valves. Under high pressure, fluid will spray sideways
from the fluid ports.
7. Flush static mixer and tip, see Flushing with Sol-
vent Purge Assembly, page 17.
8. Shut off air to solvent supply. Open solvent purge
knob (V) and relieve pressure in the solvent line.
TI2484A
TI5110b
V
To Next Page
