Parts
50 310648P
Slip-Fit Polycarballoy Mix Module Kits
Slip-Fit Polycarballoy Mix Module Part Numbering Code
*** Some modules have multiple impingement ports (see below). Size is given as the equivalence of a single port.
Direct Impingement Flat Pattern Guns
**For further infor mation, see identification chart under
Drill Bit Kits, page 51.
**For further infor mation, see identification chart under
Drill Bit Kits, page 51.
Gun and Palm Grips
Applicator's comfort level with a spray gun is an essen-
tial part of the spray foam and polyurea installation pro-
cess. The applicator's fatigue level can dramatically
affect the pattern and productivity of a project. 3M™
Gripping Material Technology is designed to:
• Reduce fatigue
• Provide comfort
• Give thermal protection
Gun Grips can be used alone to provide a strong secure
grip, or in combination with the Palm Grips to maximize
the comfort and anti-fatigue properties and minimize the
applicator's grip strength.
Gun Grip Kit
Graco Gun Grips are designed to be used on Fusion
®
A, CS, or Probler
®
P2 Guns.
Palm Grip Kit
Palm Grips are designed to adhere to any dispos-
able/removable glove.
Example
Part No.
FirstTwo Digits Second Two Dig-
its
Last Two Digits
XR3535 XR=Mechanical purge direct impingement, round pattern 35=Component A
impingement port
size (.035 in.).***
35=Component B
impingement port
size (.035 in.).***
XF3535 XF=Mechanical purge direct impingement, flat pattern
Slip-Fit Polycarballoy Mix Module
Kit (includes drill bits)
No. of Impingement
Ports
Impingement Port Drill
Bit Size, nominal**
Counterbore Drill
Bit Size, nominal**
XF1313 1 #81 #67
XF1818 1 #77 #67
XF2323 1 #74 N/A
XF2929 1 #69 N/A
XF3535 2 #73 N/A
XF4747 2 #67 N/A
XF5757 3 #67 N/A
Kit Part No. Qty in Kit
17G542 10 Pack
17G543 50 Pack
17G544 100 Pack
Kit Part No. Qty in Kit
17G545 10 Pack
17G546 50 Pack
17G547 100 Pack
