Technical Data
54 310648P
Technical Data
$OORWKHUEUDQGQDPHVRUPDUNVDUHXVHGIRULGHQWLILFDWLRQSXUSRVHVDQGDUHWUDGHPDUNVRIWKHLUUHVSHFWLYHRZQHUV
Category Data
Maximum Fluid Working Pressure 3500 psi (24.2 MPa, 242 bar)
Minimum Air Inlet Pressure 80 psi (0.55 MPa, 5.5 bar)
Maximum Air Inlet Pressure 130 psi (0.9 MPa, 9 bar)
Maximum Fluid Temperature 200° F (94° C)
Air Inlet Size 1/4 npt Quick Disconnect Nipple
Solvent Inlet Size 1/4-18 NPSM
A Component (ISO) Inlet Size -5 JIC; 1/2-20 UNF female swivel in 1/8 npt (f) port
B Component (Resin) Inlet Size -6 JIC; 9/16-18 UNF female swivel in 1/8 npt (f) port
Sound Pressure 70 dB(A), at 100 psi (0.7 MPa, 7 bar)
Sound Power, measured per ISO
9416-2
79.9 dB(A), at 100 psi (0.7 MPa, 7 bar)
Length 9 in. (228 mm)
Height 8.1 in. (206 mm)
Width 3.5 in. (89 mm)
Weight 3.7 lb (1.68 kg)
Wetted Parts
Aluminum, stainless steel, carbon steel, chemically resistant o-rings,
ultra-high molecular weight polyethylene (UHMWPE), Polycarballoy,
Nylon
Static Mixer 248642 Data
Inlet Thread 11/16-16 female straight thread
Outlet thread 11/16-16 male straight thread
Length 2.84 in. (72.2 mm)
Maximum Working Pressure 3500 psi (24.2 MPa, 242 bar)
Wetted Parts 303 stainless steel, Acetal plastic gaskets.
Disposable Static Mixer Adapter
15E244
Data
Inlet Thread 11/16-16 female straight thread
Outlet thread 7/8-14 male straight thread with tapered bell
Usage Allows the use of disposable mixers, jackets, and RAC assemblies.
