Gun Repair Kits
52 310648P
Gun Repair Kits
Read the chart left to right and top to bottom to find the quantity of each part in the kits.
Check Valve Filter Screen Kits (10 per kit)
80 mesh filter screen is standard with gun.
246357 40 mesh (.015 in., 375 micron)
246358 60 mesh (.010 in., 238 micron)
246359 80 mesh (.007 in., 175 micron)
Drill Bit Kit
Drill Bit Kit 119386
20 piece dr ill bit set #61 - #80.
Ref.
No.
Bulk O-ring
Kits, (qty)
246351
Check Valve
O-ring Kit
248887
Solvent Purge Gun
Complete O-ring Kit
14 248136 (6) 1
16 248135 (6) 1
18 248095 (6) 2
19 248096 (6) 1
20 248138 (6) 1
21 248132 (6) 1
24 246354 (6) 4*
28c 1
28h 248648 (6) 1
36f 248133 (6) 2 2
36g 248129 (6) 2 2
40c 1
40d 1
46 248003 (4) 2
*248647 only requires one #24. There will be three spares
when ordering the 248887 solvent purge gun complete o-ring
kit.
