Model 248647 Mounting Dimensions
310648P 53
Model 248647 Mounting Dimensions
Measurement Definition
in. (mm)
ti4751b
1.30 (33.0)
0.625 (15.88)
0.625
(15.88)
1 (25.4)
3 x 1/8 npt
2 x 1/4-20
2x໅ 0.127 (3.23)
1.06 (26.92)
0.73
(18.54)
4xM5
