Graco Fusion User Manual

Overall View
6 310648P
Overall View
Key:
A A Side Fluid Valve (ISO)
B B Side Fluid Valve (RESIN)
C Air Cap
D Air Line Quick Coupler
E Muffler
F Fluid Housing
G Gun Fluid Manifold
H Handle
J Optional Air Inlet
K Cleanoff Air Valve
L Piston Safety Lock
M Solvent Purge Assembly
N Optional Fluid Inlets (A Side Shown)
P Lock Ring
R Fluid Inlet Swivels (A Side Shown)
S Trigger
T Gun Air Whip Hose
U Air Valve
V Solvent Purge Valve
W Static Mixer
X RAC tip
Y Solvent Fluid Inlet
A
B
M
D
E
F
H
J
K
L
G
N
P
R
S
C
TI4966b
T
U
V
W
X
Y

Graco Fusion Specifications

General

Brand	Graco
Model	Fusion
Category	Paint Sprayer
Language	English
