Repair
310648P
33
CA
UTION
Do
not
ov
er
tighten
mix
module
nut
(25).
Over
tighten-
ing
can
deform
impingement
holes
and
cause
slow
gun
actuation.
5.
Lubricate
all
threads
and
reassemble
mix
module
nut
(25)
finger
tight
.
Tighten
additional
1/12
tur
n
with
wrench.
Install
front
seal
(46)
on
rod
(31).
1/12
Turn
TI4986a
46
25
31
6.
Reinstall
solvent
purge
assembly
(28).
Lubricate
all
threads.
Install
static
mixer
(40)
and
RAC
tip
(9).
Tighten
with
wrench.
TI5002b
9
40
28
32
34
