Graco PrecisionSwirl - Page 142

Appendix C - Communications Gateway Module (CGM) Connection Details
142 3A2098S
0x303 Flow meter
Maintenance -
Dispensed Vol-
ume*
Volume: ######
(gal(US)); ######
(gal(Uk)); ######
(Liters); Mass: ######
(lb), ###### (kg)
Read /
Write
0x304 Supply Mainte-
nance - Dis-
pensed
Volume*
Volume: ######
(gal(US)); ######
(gal(Uk)); ######
(Liters); Mass: ######
(lb), ###### (kg)
Read /
Write
0x305 V/P Mainte-
nance - Dis-
pensed
Volume*
Volume: ######
(gal(US)); ######
(gal(Uk)); ######
(Liters); Mass: ######
(lb), ###### (kg)
Read /
Write
0x308 Valve 1 Main-
tenance - Dis-
pensed
Volume*
Volume: ######
(gal(US)); ######
(gal(Uk)); ######
(Liters); Mass: ######
(lb), ###### (kg)
Read /
Write
0x309 Valve 2 Main-
tenance - Dis-
pensed
Volume*
Volume: ######
(gal(US)); ######
(gal(Uk)); ######
(Liters); Mass: ######
(lb), ###### (kg)
Read /
Write
0x30A Valve 3 Main-
tenance - Dis-
pensed
Volume*
Volume: ######
(gal(US)); ######
(gal(Uk)); ######
(Liters); Mass: ######
(lb), ###### (kg)
Read /
Write
0x30B Valve 4 Main-
tenance - Dis-
pensed
Volume*
Volume: ######
(gal(US)); ######
(gal(Uk)); ######
(Liters); Mass: ######
(lb), ###### (kg)
Read /
Write
0x312 Regulator
Maintenance -
Dispense
Time*
###### (hours) Read /
Write
0x313 Flow meter
Maintenance -
Dispense
Time*
###### (hours) Read /
Write
0x314 Supply Mainte-
nance - Dis-
pense Time*
###### (hours) Read /
Write
0x315 V/P Mainte-
nance - Dis-
pense Time*
###### (hours) Read /
Write
0x318 Valve 1 Main-
tenance - Dis-
pense Time*
###### (hours) Read /
Write
0x319 Valve 2 Main-
tenance - Dis-
pense Time*
###### (hours) Read /
Write
Output
Bits
256-267 Description
Units
*See
Units
Definitions, page 145
Read or
Write
0x31A Valve 3 Main-
tenance - Dis-
pense Time*
###### (hours) Read /
Write
0x31B Valve 4 Main-
tenance - Dis-
pense Time*
###### (hours) Read /
Write
0x800 Purge Defini-
tion - Volume
#####.# (cc) Read /
Write
0x801 Purge Defini-
tion - Pressure
Pressure: #### (psi);
###.# (bar); ##.##
(Mpa)
Read /
Write
0x802 Purge Defini-
tion - Toler-
ances
Tolerances Type Read /
Write
0x803 Purge Defini-
tion - Duration
#### (seconds) Read /
Write
0x804 Style 1 Defini-
tion - Volume
#####.# (cc) Read /
Write
0x805 Style 1 Defini-
tion - Pressure
Pressure: #### (psi);
###.# (bar); ##.##
(Mpa)
Read /
Write
0x806 Style 1 Defini-
tion - Toler-
ances
Tolerances Type Read /
Write
0x807 Style 1 Defini-
tion - Pre-
charge
Settings
Precharge Settings
Type
Read /
Write
0xBFC Style 255 Defi-
nition - Volume
#####.# (cc) Read /
Write
0xBFD Style 255 Defi-
nition - Pres-
sure
Pressure: #### (psi);
###.# (bar); ##.##
(Mpa)
Read /
Write
0xBFE Style 255 Defi-
nition - Toler-
ances
Tolerances Type Read /
Write
0xBFF Style 255 Defi-
nition - Pre-
charge
Settings
Precharge Settings
Type
---
0xC04 Style 1 Defini-
tion - Name
STR_3_0 Read /
Write
0xC05 Style 1 Defini-
tion - Name
STR_7_4 Read /
Write
0xC06 Style 1 Defini-
tion - Name
STR_11_8 Read /
Write
0xC07 Style 1 Defini-
tion - Name
STR_15_12 Read /
Write
0xC3C Style 15 Defini-
tion - Name
STR_3_0 Read /
Write
0xC3D Style 15 Defini-
tion - Name
STR_7_4 Read /
Write
Output
Bits
256-267 Description
Units
*See Units
Definitions, page 145
Read or
Write
