Appendix C - Communications Gateway Module (CGM) Connection Details
3A2098S 141
0x26E V/P Vol-
ume/Mass
Advisory Limit
Volume: ######
(gal(US)); ######
(gal(Uk)); ######
(Liters); Mass: ######
(lb), ###### (kg)
Read /
Write
0x270 Valve 1 Time
Advisory Limit
###### (hours) Read /
Write
0x271 Valve 2 Time
Advisory Limit
###### (hours) Read /
Write
0x272 Valve 3 Time
Advisory Limit
###### (hours) Read /
Write
0x273 Valve 4 Time
Advisory Limit
###### (hours) Read /
Write
0x278 Valve 1 Vol-
ume/Mass
Advisory Limit
Volume: ######
(gal(US)); ######
(gal(Uk)); ######
(Liters); Mass: ######
(lb), ###### (kg)
Read /
Write
0x279 Valve 2 Vol-
ume/Mass
Advisory Limit
Volume: ######
(gal(US)); ######
(gal(Uk)); ######
(Liters); Mass: ######
(lb), ###### (kg)
Read /
Write
0x27A Valve 3 Vol-
ume/Mass
Advisory Limit
Volume: ######
(gal(US)); ######
(gal(Uk)); ######
(Liters); Mass: ######
(lb), ###### (kg)
Read /
Write
0x27B Valve 4 Vol-
ume/Mass
Advisory Limit
Volume: ######
(gal(US)); ######
(gal(Uk)); ######
(Liters); Mass: ######
(lb), ###### (kg)
Read /
Write
0x283 Swirl Fault
Error Type
Error Type Enumera-
tion 2
0x284 Low Flow Rate
Error Type
Error Type Enumera-
tion 1
Read /
Write
0x285 High Flow Rate
Error Type
Error Type Enumera-
tion 1
Read /
Write
0x286 Low Pressure
Error Type
Error Type Enumera-
tion 1
Read /
Write
0x287 High Pressure
Error Type
Error Type Enumera-
tion 1
Read /
Write
0x289 High Outlet
Pressure Error
Type
Error Type Enumera-
tion 2
Read /
Write
0x28A Low Volume
Error Type
Error Type Enumera-
tion 1
Read /
Write
0x28B High Volume
Error Type
Error Type Enumera-
tion 1
Read /
Write
0x28C Low Com-
puted Target
Error Type
Error Type Enumera-
tion 1
Read /
Write
Output
Bits
256-267 Description
Units
*See Units
Definitions, page 145
Read or
Write
0x28D High Com-
puted Target
Error Type
Error Type Enumera-
tion 1
Read /
Write
0x28E Low Inlet Pres-
sure Error
Type
Error Type Enumera-
tion 2
Read /
Write
0x28F High Inlet
Pressure Error
Type
Error Type Enumera-
tion 2
Read /
Write
0x292 Valve 1 Mode Valve Mode Enumera-
tion
Read /
Write
0x293 Valve 2 Mode Valve Mode Enumera-
tion
Read /
Write
0x294 Valve 3 Mode Valve Mode Enumera-
tion
Read /
Write
0x295 Valve 4 Mode Valve Mode Enumera-
tion
Read /
Write
0x296 Valve 1 10
VDC Analog
Scale Flow
rate
Volume: #####
(cc/sec); #####
(cc/min); Mass: #####
(g/sec); ##### (g/min)
Read /
Write
0x297 Valve 2 10
VDC Analog
Scale Flow
rate
Volume: #####
(cc/sec); #####
(cc/min); Mass: #####
(g/sec); ##### (g/min)
Read /
Write
0x298 Valve 3 10
VDC Analog
Scale Flow
rate
Volume: #####
(cc/sec); #####
(cc/min); Mass: #####
(g/sec); ##### (g/min)
Read /
Write
0x299 Valve 4 10
VDC Analog
Scale Flow
rate
Volume: #####
(cc/sec); #####
(cc/min); Mass: #####
(g/sec); ##### (g/min)
Read /
Write
0x29A Valve 1 10
VDC Analog
Scale Pressure
Pressure: #### (psi);
###.# (bar); ##.##
(Mpa)
Read /
Write
0x29B Valve 2 10
VDC Analog
Scale Pressure
Pressure: #### (psi);
###.# (bar); ##.##
(Mpa)
Read /
Write
0x29C Valve 3 10
VDC Analog
Scale Pressure
Pressure: #### (psi);
###.# (bar); ##.##
(Mpa)
Read /
Write
0x29D Valve 4 10
VDC Analog
Scale Pressure
Pressure: #### (psi);
###.# (bar); ##.##
(Mpa)
Read /
Write
0x302 Regulator
Maintenance -
Dispensed Vol-
ume*
Volume: ######
(gal(US)); ######
(gal(Uk)); ######
(Liters); Mass: ######
(lb), ###### (kg)
Read /
Write
Output
Bits
256-267 Description
Units
*See Units
Definitions, page 145
Read or
Write
