Graco PrecisionSwirl - Page 77

Errors
3A2098S 77
MED_ 79 Maintenance
Due - V/P
Maintenance due for
Voltage to Pressure
Transducer
Advisory Totalizer exceeded
limit setting
Service component
If necessary, reset
totalizer
MCD_ 80 Maintenance
Due - Supply
Maintenance due for
supply system
Advisory Totalizer exceeded
limit setting
Service component
If necessary, reset
totalizer
MD1_ 81 Maintenance
Due - Valve 1
Maintenance due for
valve 1
Advisory Totalizer exceeded
limit setting
Service component
If necessary, reset
totalizer
MD2_ 82 Maintenance
Due - Valve 2
Maintenance due for
valve 2
Advisory Totalizer exceeded
limit setting
Service component
If necessary, reset
totalizer
MD3_ 83 Maintenance
Due - Valve 3
Maintenance due for
valve 3
Advisory Totalizer exceeded
limit setting
Service component
If necessary, reset
totalizer
MD4_ 84 Maintenance
Due - Valve 4
Maintenance due for
valve 4
Advisory Totalizer exceeded
limit setting
Service component
If necessary, reset
totalizer
CCD_ 85 Duplicate Module Duplicate Fluid Control
Module Detected
Alarm Two or more FCMs
have the same rotary
switch setting
Verify that all FCMs
have proper rotary
switch settings. Reset
module after changing
rotary switch setting.
Refer to Fluid Plate
Assembly Overview
section, page 17
EAD_
86 Swirl Mainte-
nance Mode
Entered
Swirl maintenance
mode entered
Advisory
(self-clearing)
Swirl zone that is
associated with this
fluid plate entered
maintenance mode
No action required
WFC_
87 Shot No-Flow
Timeout
No flow detected for
five seconds on valve
activated in shot mode
Alarm Dispense valve not
operating properly
Check dispense valve
for correct operation
and/or clogging
Fluid leak Check fluid connec-
tions
CR1_
88 Valve 1 Swirl
Communication
Error
Fluid plate communica-
tion error with swirl
Alarm The fluid plate lost
communication with
the swirl zone associ-
ated with this valve
and fluid plate
Restore communica-
tions.
CR2_
89 Valve 2 Swirl
Communication
Error
Fluid plate communica-
tion error with swirl
Alarm The fluid plate lost
communication with
the swirl zone associ-
ated with this valve
and fluid plate
Restore communica-
tions.
Event
Code
Gateway
Error No. Event Name
Event
Description Event Type Cause Solution
Fluid Plate Events and Errors
