Graco PrecisionSwirl - Errors; Fluid Plate Events and Errors

Errors
78 3A2098S
CR3_ 90 Valve 3 Swirl
Communication
Error
Fluid plate communica-
tion error with swirl
Alarm The fluid plate lost
communication with
the swirl zone associ-
ated with this valve
and fluid plate
Restore communica-
tions.
CR4_
91 Valve 4 Swirl
Communication
Error
Fluid plate communica-
tion error with swirl
Alarm The fluid plate lost
communication with
the swirl zone associ-
ated with this valve
and fluid plate
Restore communica-
tions.
WD1_
92 Valve 1 Swirl
Fault
Swirl motor fault Alarm or
Deviation
(user-select-
able)
The swirl zone associ-
ated with this valve
and fluid plate caused
a fault
Resolve swirl motor
fault (see error WBDX
for possible solutions)
WD2_ 93 Valve 2 Swirl
Fault
Swirl motor fault Alarm or
Deviation
(user-select-
able)
The swirl zone associ-
ated with this valve
and fluid plate caused
a fault
Resolve swirl motor
fault (see error WBDX
for possible solutions)
WD3_ 94 Valve 3 Swirl
Fault
Swirl motor fault Alarm or
Deviation
(user-select-
able)
The swirl zone associ-
ated with this valve
and fluid plate caused
a fault
Resolve swirl motor
fault (see error WBDX
for possible solutions)
WD4_
95 Valve 4 Swirl
Fault
Swirl motor fault Alarm or
Deviation
(user-select-
able)
The swirl zone associ-
ated with this valve
and fluid plate caused
a fault
Resolve swirl motor
fault (see error WBDX
for possible solutions)
MB1_ 96 Maintenance due
- V1 Orbiter
Maintenance due on
valve 1 swirl orbiter
Advisory The active time total-
izer for the swirl dis-
penser associated
with this valve and
fluid plate exceeded
limit setting
Service Component
If necessary, reset
totalizer
MB2_
97 Maintenance due
- V2 Orbiter
Maintenance due on
valve 2 swirl orbiter
Advisory The active time total-
izer for the swirl dis-
penser associated
with this valve and
fluid plate exceeded
limit setting
Service Component
If necessary, reset
totalizer
MB3_
98 Maintenance due
- V3 Orbiter
Maintenance due on
valve 3 swirl orbiter
Advisory The active time total-
izer for the swirl dis-
penser associated
with this valve and
fluid plate exceeded
limit setting
Service Component
If necessary, reset
totalizer
MB4_
99 Maintenance due
- V4 Orbiter
Maintenance due on
valve 4 swirl orbiter
Advisory The active time total-
izer for the swirl dis-
penser associated
with this valve and
fluid plate exceeded
limit setting
Service Component
If necessary, reset
totalizer
Event
Code
Gateway
Error No. Event Name
Event
Description Event Type Cause Solution
Fluid Plate Events and Errors
