P a g e | 23
GWN7610/GWN7600/GWN7600LR User Manual
Version 1.0.8.18
Operation: 0°C to 40°C
Storage: -10°C to 60°C
Humidity: 10％ to 90% Non-condensing
Unit Dimension: 205.3 x 205.3 x 45.9mm; Unit Weight: 526g
Unit + Mounting Kits Dimension: 205.3 x 205.3 x 53.9mm; Unit + Mounting Kits
Weight : 610g
Entire Package Dimension: 228.5*220*79mm; Entire Package Weight: 854g
GWN7600 Wave-2 802.11ac Wireless AP, Mounting Kits, Quick Installation Guide
Table 3: GWN7600LR Technical Specifications
IEEE 802.11 a/b/g/n/ac (Wave-2)
2x 2.4 GHz, gain 4 dBi, internal antenna
2x 5 GHz, gain 5 dBi, internal antenna
IEEE 802.11ac: 6.5 Mbps to 867 Mbps
IEEE 802.11a: 6, 9, 12, 18, 24, 36, 48, 54 Mbps
IEEE 802.11n: 6.5 Mbps to 300 Mbps; 400Mbps with 256-QAM on 2.4GHz
IEEE 802.11b: 1, 2, 5.5, 11 Mbps
IEEE 802.11g: 6, 9, 12, 18, 24, 36, 48, 54 Mbps
*Actual throughput may vary depending on many factors including environmental conditions, distance
between devices, radio interference in the operating environment and mix of devices in the network
2.4GHz radio: 2.400 - 2.4835 GHz
5GHz radio: 5.150 - 5.250 GHz, 5.725 - 5.850 GHz
2.4G: 20 and 40 MHz, 5G: 20,40 and 80 MHz
Wi-Fi and System
Security
WEP, WPA/WPA2-PSK, WPA/WPA2 Enterprise (TKIP/AES), anti-hacking secure
boot and critical data/control lockdown via digital signatures, unique security
certificate and random default password per device
2x2:2 2.4GHz (MIMO),
2x2:2 5GHz (MU-MIMO)
Up to 984ft. (300 meters)
*Coverage range can vary based on environment
5G: 22dBm (FCC) / 20dBm (CE)
2.4G: 22dBm (FCC) / 17dBm (CE)
*Maximum power varies by country, frequency band and MCS rate
2.4G
802.11b: -99dBm@1Mbps, -91dBm@11Mbps; 802.11g:-93dBm@6Mbps,
