GWN7610/GWN7600/GWN7600LR User Manual
Version 1.0.8.18
Filtering Options
Source Port
Set the Source Port to filter capture traffic coming from the defined source port.
Destination Port
Set the Destination Port to filter capture traffic coming from the defined port.
Source IP
Set the Source IP to filter capture traffic coming from the defined source IP.
Destination IP
Set Destination IP to filter capture traffic coming from the defined destination IP.
Protocol
Choose ALL or a specific protocol to capture (IP, ARP, RARP, TCP, UDP, ICMP,
IPv6)
 Click on to start capturing on a certain device plugged to the USB port.
 Click on to stop the capture.
Click on to show the captured files on a chosen device, users could check the capture
files details.
 Click on to delete all files.
 Click on next to a capture file to download it on a local folder.
 Click on to delete the corresponding capture file.
Figure 57: Capture Files
