INSTALLATION
Before deploying and configuring the GWN7610/GWN7600/GWN7600LR, the device needs to be properly
powered up and connected to the network. This section describes detailed information on installation,
connection and warranty policy of the GWN7610/GWN7600/GWN7600LR.
Equipment Packaging
Table 4: GWN7610/GWN7600 Equipment Packaging
Main Case (GWN7610 or GWN7600)
Yes (1)
Mounting Bracket
Yes (1)
Ceiling Mounting Bracket
Yes (1)
Plastic Expansion Bolt
Yes (3)
M3 NUT
Yes (3)
Screw (PM 3 x 50)
Yes (3)
Screw (PM 3.5 x 20)
Yes (3)
Quick Installation Guide
Yes (1)
GPL License
Yes (1)
Figure 1: GWN7610 or GWN7600 Equipment Package
GWN7610 or GWN7600
