GWN7610/GWN7600/GWN7600LR User Manual
Version 1.0.8.18
BANDWIDTH RULES
The bandwidth rule is a GWN7610/GWN7600/GWN7600LR feature that allows users to limit bandwidth
utilization per SSID or client (MAC address or IP address).
This option can be configured from the GWN7610/GWN7600/GWN7600LR WebGUI under “Bandwidth
Rules”.
Click to add a new rule, the following table provides an explanation about different options
for bandwidth rules.
Table 17: Bandwidth Rules
Enable/Disable the Bandwidth rule.
Select which SSID will be affected by the bandwidth rule limitation.
Choose the type of rule to be applied on bandwidth utilization from the
dropdown list, three options are available:
Per-SSID: Set a bandwidth limitation on the SSID level.
Per-User: Set a bandwidth limitation per Client.
MAC: Set a bandwidth limitation per MAC address.
IP Address: Set a bandwidth limitation per IP address.
Enter the MAC address of the device to which the limitation will be
applied, this option appears only when MAC type is selected.
Enter the IP address of the device to which the limitation will be applied,
this option appears only when IP Address type is selected.
Enable this option to assign a schedule for the bandwidth rule.
Specify the limit for the upload bandwidth using Kbps or Mbps.
Specify the limit for the download bandwidth using Kbps or Mbps.
