14
Set Shrink/Stretch Ratio
To compensate for printer image shift, the PT 331SCC is equipped with a
shrink/stretch feature. This function is designed to balance any image shrink
or stretch that may have happened while printing. This will shift cuts up or
down by a percentage without changing the card size.
Press Increase Key to increase the ratio by 0.1% or press Decrease Key to decrease the ratio by 0.1%. Press Enter
to save changes.
Horizontal Shift Screen
This function is designed to balance any image shift that may have occurred
while printing. This will move all cuts up or down by an equal amount without
changing the card size. Press the increase Key to increase the value by 0.1mm
(0.0039”) or press the decrease Key to decrease the value by 0.1mm. Press
Enter to save the changes.
Card Length Offset Screen
This function is designed to compensate for card length changes due to image
shift or print placement. It will increase or decrease the card size. Press the
Decrease Key to decrease the value by 0.1mm (0.0039”) or press the Increase
Key to increase the value by 0.1mm. Press Enter to save changes.
Gutter Offset Screen
To increase or decrease the cut gutter size for print offset, press the Decrease
Key to decrease the value by 0.1mm (0.0039”) or press the Increase Key to
increase the value by 0.1mm. Press Enter to save changes.
Note: To avoid a tail trim error, the last cut on the sheet must be smaller than 0.59” and larger than 0.197”.
All image compensations functions are limited by the PT 331SCC parameters, as follows:
• First Cut: 0.12” - 0.59” (3.2mm - 15mm)
• Gutter Cut: 0.12” - 0.59” (3.2mm - 15mm)
• Last Cut: 0.197” - 0.59” (5mm - 15mm)
Save Job Screen
Use this function to save a user specific template. The max storage is 30
templates. If a job has already been saved under the specified number, the PT
331SCC will request confirmation to override. Press enter to override. The
new job will be saved in that spot.
