July 28, 2008 K2 Media Client Service Manual 45
Install the loop-back adapter
• “Name team”
• “Reorder adapters”
Install the loop-back adapter
When you receive a K2 Media Client from the factory, it has a loop-back adapter
installed. This is true for all storage types. Use the following procedure to restore the
loop-back adapter:
1. In the Windows Control Panel, open
Add Hardware and then click Next.
2. Click
Yes, I have already connected the hardware, and then click Next.
3. At the bottom of the list, click
Add a new hardware device, and then click Next.
4. Click
Install the hardware that I manually select from a list, and then click Next.
5. Click
Network adapters, and then click Next.
6. In the Manufacturer box, click
Microsoft.
7. In the Network Adapter box, click
Microsoft Loopback Adapter, and then click Next.
8. Click
Next, then Finish.
9. In Control Panel, go to
Network Connections.
10.Find the connection that reports itself in the Device Name column as the loopback
adapter. Right-click on this icon and rename the connection to
Loopback.
11.Right-click on the Loopback icon and select
Properties.
12. Select
Internet Protocol (TCP/IP) and click the Properties button.
13.Click
Use the following IP address and set the address to 192.168.200.200 and
set the subnet mask to 255.255.255.0.
NOTE: The Microsoft Loopback Adapter must have its IP address set to
192.168.200.200. If a different IP address is used the stand-alone storage K2 Media
Client can not access its own media file system.
14.Click
OK and Close to exit.
15.Return to
Network Connections in Control Panel.
16.On the menu bar at the top of the window, select
Advanced, then Advanced
Settings…
17.On the Adapters and Bindings tab move the Loopback connection to the end of the
LAN adapters in the list (leaving it above Remote Access connections).
18.Click
OK to exit.
19.Continue with the next procedure “Identify adapters”.
Identify adapters
1. Open Device Manager as follows:
a. On the Windows desktop, right-click
K2 Media Client (My Computer) and select
