86 K2 Media Client Service Manual July 28, 2008
Chapter 4 Troubleshooting problems
SCSI controller adapter BIOS startup information
The following information appears on the locally connected VGA monitor during a
normal startup of the K2 Media Client. This is a part of the BIOS Power On Self Test
(POST) generated by the SCSI controller adapter.
Information Explanation
LSI MegaRAID BIOS Version… SCSI controller adapter BIOS and firmware
version information
Copyright… Copyright information for the manufacturer of the
SCSI controller adapter.
Initializing SCSI controllers
Scanning…
Checking…
Spinning…
Reading…
This list of flashing messages refer to the startup of
the internal RAID drives and their supporting
components.
HA-1 (Bus 3 Dev 0) MegaRAID SCSI 320-2X Report of the SCSI controller adapter
Standard FW 413Z DRAM = 128 MB (SDRAM) Report of firmware and memory installed on the
SCSI controller adapter.
6 Logical drives found… A report of the LUNs (groups of RAID drives)
currently installed. Internal storage models have
multiple LUNs. External storage models have one
LUN.
6 Logical drives handled…
Press <Ctrl> <M> to run Configuration Utility This is the SCSI controller adapter configuration.
Do not press these keys. All settings should be left
at their default values.
Press <Ctrl> <H> for WebBIOS
