GRASS VALLEY K2 Service Manual

July 28, 2008 K2 Media Client Service Manual 79
Installing the Fibre Channel card driver
• If the file is not present, procure the file from ftp://ftp.thomsongrassvalley.com/
pub/K2/Microcode_and _Drivers/LSI_SCSIPORT. The filename is
LSI_SCSIPORT_1.21.25.00.zip. Then continue with this procedure
2. After restoring the disk image and restarting the K2 Media Client, a Found New
Hardware wizard opens for the Fibre Channel controller. Install the driver on the
first FC port as follows:
a. Select
Install from a list or specific location. Click Next.
b. Select
Don’t search. I will choose the driver to install. Click Next.
c. Select
SCSI and Raid Controllers and Have Disk.
d. Browse to C:\profile\drivers\LSI_SCSIPORT_1.21.25.00. Click
Open and OK.
e. Start the driver install by selecting
Next.
f. On the Hardware Installation page, click
Continue Anyway.
g. Click
Finish.
3. If the K2 Media Client has a dual port Fibre Channel card, on the Found New
Hardware wizard, install the driver on the second FC port as follows:
a. Select
Install from a list or specific location. Click Next.
b. Select
Don’t search. I will choose the driver to install. Click Next.
c. Select
Have Disk.
d. Browse to C:\profile\drivers\LSI_SCSIPORT_1.21.25.00. Click
Open and OK.
e. Start the driver install by selecting
Next.
f. On the Hardware Installation page, click
Continue Anyway.
g. Click
Finish.
4. On the Found New Hardware wizard, install the first LSI Pseudo Device as
follows:
a. Select
Install from a list or specific location. Click Next.
b. Select
Don’t search. I will choose the driver to install. Click Next.
c. Select
Have Disk.
d. Browse to C:\profile\drivers\LSI_SCSIPORT_1.21.25.00. Click
Open and OK.
e. Start the driver install by selecting
Next.
f. On the Hardware Installation page, click
Continue Anyway.
g. Click
Finish.
5. If the K2 Media Client has a dual port Fibre Channel card, on the Found New
Hardware wizard, install the driver on the second LSI Pseudo Device port as
follows:
a. Select
Install from a list or specific location. Click Next.
b. Select
Don’t search. I will choose the driver to install. Click Next.
