First contact
L-SOLUTION 700 / 800 / 900 machines . 97
8. Validate
The head of the machine moves towards the centre of the engraving table and an autofocus is effected automatically
(pict. 1).
Autofocus adjustment
The following message will be displayed on the L.C.D. screen of the machine:
RE-ALIGN Z
JOYSTICK Z
Z = ZZ.ZZ
9. Open the front door of the LASER machine
10. Place the wedge for the autofocus adjustment (provided with the machine) on the engraving
table, just below the lens support of the LASER head (pict. 2)
11. Go up the engraving table until the lens support of the head touches slightly the wedge
(pict. 3) using the arrows keys
