Gree GMV-S280W/A-X

GMV5 Home DC Inverter Multi VRF Units
238
20
Reserved
21
Module temperature of compressor 1
22
Module temperature of compressor 2
23
Module temperature of outdoor fan 1
24
Module temperature of outdoor fan 2
25
Outdoor unit heating EXV1
26
Outdoor unit heating EXV 2
27
Subcooler EXV
28
Defrosting temperature
29
Liquid-extracting temperature of
subcooler
30
Outlet temperature of steam
separator
31
Oil return temperature
This parameter is invalid for the
GMV Unic series
32
Inlet-tube temperature of condenser
33
Outlet temperature of condenser
Notes:
①If a parameter value is negative, LED3 will circularly display the negative code ―nE‖ and the
numeric value at every one second. For example, for -30°C, LED3 will alternately display ―nE‖ for
one second and then ―30‖ for another second.
②The discharge temperature and ambient temperature will be displayed as four-digit values,
circularly displaying the higher two digits and then the lower two digits. For example, if 01 and 15
are alternately displayed, it indicates 115°C. If nE, 00, 28 are alternately displayed, it indicates
-28°C.
③ If a parameter is invalid for the unit, ―00‖ is displayed. If no button operations are
performed on the master unit for five minutes, the function setting will automatically quit and the
unit will resumes to the current status.
Step 9: If the ―nb ODU barcode inquiry‖ is selected, it will display as below and enter into
―to-be-confirmed status of ODU barcode inquiry‖.
LED1
LED2
LED3
Function Code
Display Mode
Current Progress/Mode
Display Mode
Current Status
Display Mode
nb
Flicker
00
Flicker
00
Flicker
Press SW7 on the master unit to enter into the next-level menu selection. The display is as
below:
LED1
LED2
LED3
Function Code
Display Mode
Module Address
Display Mode
Current Status
Display Mode
nb
On
01
Flicker
00
Flicker
Select corresponding outdoor unit for inquiry by pressing SW1 (▲) and SW2 (▼) and then
press SW7 to confirm. The display is as below:
LED1
LED2
LED3
