3 Installation
Topics Covered in this Chapter
▪ Power Sweeps in Bins with Concrete Floors
▪ Installing the Center Well
▪ Installing the Bin Flange for Unload Tube
▪ Installing the Intermediate Well
▪ Installing the Center Well Gate
▪ Installing the Intermediate Well Gate
▪ Installing the Rack and Pinion
▪ Installing the Intermediate Well Flange
▪ Assembling the Sweep Flighting to the Backshield (60' - 72' Bins)
▪ Installing the Sweep Flighting
▪ Installing the Flighting Shield
▪ Installing the Sweep Wheel Assembly
▪ Installing the Backshield Support Assembly
▪ Adjusting the Wiper
▪ Assembling and Adjusting the Sweep Support Skid (60' - 72' Bins)
▪ Installing the Sweep Stop
▪ Drive Assembly and Power Tube Layout
▪ Installing the Power Tube
▪ Assembling the Drive Shafts (42' - 72' Only)
▪ Installing the Bin Flanges for Power tube
▪ Assembling the Drive Head
PNEG-2308 Chain Loop Power Sweep
