Chapter 4: Operation
Operating the Sweep Stop
1. Before filling the bin with grain, make sure to place the sweep stop (106) at the down position.
2. Operate to complete the sweep cycle until the sweep is stopped by the sweep stop (106).
Figure 4-12 Sweep stop at down position
106 Sweep stop 107 Cable
3. If the sweep wheel will not pass by the door frame, adjust the wheel to have clearance from the door
frame.
4. Once the wheel passes the door frame, adjust the wheel back to the extended position. For details,
refer to Adjusting the Sweep Wheel, page 64.
5. If the wheel doesn’t interfere with the door frame, lift the sweep stop (106) using the cable (107) to
up position to let the wheel run through.
Figure 4-13 Sweep stop at up position
106
Sweep stop
107
Cable
PNEG-2308 Chain Loop Power Sweep
65
