Chapter 3: Installation
3. Attach the deflector plate (100) to the sweep wheel assembly (99) using the supplied 5/16" bolts
(27).
Figure 3-31 Attaching the deflector plate to the sweep wheel assembly
27 5/16" bolt 100 Deflector plate
99 Sweep wheel assembly
