Chapter 7: Parts List
Table 7-1 Center well parts list
Ref # Part #
Description
1
8081458-Y Center Well Weldment - 8" Ochre
8101972-Y Center Well Weldment - 10" Ochre
8120379-Y Center Well Weldment - 12" Ochre
2 8101667 Center Well Plate Cover
3 S-6606
Bolt, Flange 5/16"-18 x 3/4" ZN Clear Grade 5
4
GK1055
Band: Half 8" x 2" 12 Gauge Galvanized
GK1057
Band: Half 10" x 2" 12 Gauge Galvanized
GK2926
Band: Half 12" x 2" 12 Gauge Galvanized
5
S-9350
Bolt, HHCS 5/16"-18 x 1-1/4" YDP Grade 8
6 S-7382
Nut, Nylock 5/16"-18 ZN Grade 5
7 S-3611
Nut, Flange 5/16"-18 YDP Grade 2
8
8101970 Center Well Gate - 8" and 10"
8120377 Center Well Gate - 12"
9 S-10810
Bolt, Carriage 5/16" x 2-14" ZN Grade 5
10 GK81553
Center Well Control Rod Spacer
11 S-8760
Bolt, HHTB 1/2"-13 x 1-1/2" ZN Grade 5
12 MHC01055
Bearing, Radial 1.375" OD, 0.50" ID
13 S-2120
Washer, Flat 1/2" SAE ZN
14 S-7149
Bolt, HHTB 5/16"-18 x 1-3/4" ZN Grade 5
15 S-8506
Nut, Flange 1/2"-13 ZN
16 8101766
Gearbox, CGD Upper 1.35:1 Ratio, Extended Shaft
17 S-9168
Key, Square 1/4" x 1"
18 S-9062
Bolt, Flange 1/2"-13 x 1-1/4" ZN Grade 5
19 8101715
Pivot Plate Assembly
20 AS-0920
Sprocket, #60 13T 1" Bore with Set Screws
21 8101726
Roller Chain #60, 47 Pitches
22 8101767
Gearbox, CGD Lower 1.25:1 Ratio
23 S-8132
Bolt, HHTB 3/8"-16 x 3" ZN Grade 2
24 S-968
Nut, Flange 3/8"-16 ZN Grade 5 Wide Flange
25 S-7383
Nut, Nylock 3/8"-16 ZN Clear Grade 5
26 8101725
Gearbox Tension Angle IRN
27 8101901
Flex Coupler with Chain
28 C-7519
Leveling Leg
29 S-234
Nut, Hex 3/4"-10 ZN Grade 5, Zinc Plated
30 8101974 Center Well Control Rod
31 GK80532-BS
Control Pipe Coupling - Bin Silver
32 8101977 Control Rod Extension
33 S-10185
Bolt, Flange 5/16"-18 x 1-1/2" ZN Grade 5
PNEG-2308 Chain Loop Power Sweep
